GD&T Perpendicularity for End Components and End Cuts

Perpendicularity is a measurement used to determine how perpendicular end cuts or components are relative to the centerline axis of an attached cylinder.


The final value is not an angle. It is the maximum distance along the centerline between two points in end scan points.
